Krismar Exclusive 5 Horse in Build
- New Volvo FH 500 RHD euro 6 6x2 fully automatic gearing, full air suspension, steering 3rd axle, Rockinger for big trailer,
- Adaptive Cruise Control, GSR package
- New Volvo FH 500 RHD euro 6 6x2 fully automatic gearing, full air suspension, steering 3rd axle, Rockinger for big trailer,
- Adaptive Cruise Control, GSR package
Length: 11,990 mm | Width: 2,530 mm | Height: 3,980 mm
- RHD build!!
- From aluminium profiles with heat insulation
- Polyester sheet covering from exterior
- Individually adapted structural parts for each chassis
- Robust and self-contained construction
- Treated and painted inner wall structures
- Easily accessible engine (tilt able cab)
- Electrical pop-out on the right-side front for sofa
- Electrical pop-out on the left side front for kitchen
- Electrical pop-up in sleeping place above the bathroom
- Rear ramp made of aluminium construction, special non-slip ramp-rubber matting, spring assisted, with synthetic guides in both sides
- NO side ramp
- Cabinet and locker box on the left side for saddles and bridles
- Waterjet for horses
- Tack box with lift installed in left side front
- Extra 230V special secured socket for E-bikes in the front tack box compartment
- Skirts, spoilers
- High security electric system
- AC connector and water inlets in the skirt aircon compartment
- 4 Victron batteries
- 12V/24V/230V Victron system on board
- 5Kw Onan silent power generator
- Brustor sun awning on horse area with LED lighting
- Colour: Land Rover White Gold -Black Optical
- 3.5-ton trailer connection installed
The living area can be accessed straight from the driver's cabin, through the entrance door from outside or straight from the horse area.
- Folding entrance stairs
- Code lock system on doors
- Large, heated storage under the living
- Full cutting between the living area and the cab
- Floor level in cabin equal to the living area
- Cab seats upholstered with genuine leather matching living
- 2 extra turn able driving seats installed in the cabin
- Electrical lifting bed system installed in the cabin
- Walls covered with artificial leather coating
- Floor covering and artificial leather covering on the ceiling
- Ceiling with wood inlays for lighting
- Double glazed windows with sun and insect protection system
- Furniture made of wood, integrated LED striping bottom and ceiling of furniture
- Fake ceiling with indirect LED stripe
- Top units above seats and kitchen
- Electric pop-out system on the right-side front with windows on sides:
- Sofa in pop-out with L&R sofa, convertible to U-shape sofa by sliders and removable back and seat rest.
- 4 approved seats during driving
- Extra cushion to create an extra bed
- Table double foldable into the window direction
- Big drawers in the L&R sofa’s
- Top units
- 230V, USBc, sockets and wireless phone charging in the corners
- 6 sleeping places – 2 in top cabin; 2 in pop-out; 2 over the bathroom with entrance from living with shutter system, and entrance from horse part
- Fresh (500 litre) water tank insulated and heated
- Waste (250 litre) and toilet (150 litre) water-tank insulated with electrical opener system in cabin
- Water tanks and tubes heated
- Central hot and cold water
- Split air condition system above the TV wall
- Extra Domestic aircon installed for bedroom above bathroom, and cold air inlet (closable) for bathroom.
- Webasto heating system
- Electrical floor heating in living, gangway, bathroom
- Electrical pop-out system on the left side front with working surface:
- Stainless steel integrated sink with marble cover plate to enlarge kitchen surface
- Electric ceramic cooker with air outtake
- BIG refrigerator with freezer compartment
- Combi microwave oven
- Waste bin
- Top units
- 230V sockets working over the battery
- Central vacuum cleaner installed
- Smart TV 43” in living area with sound bar
- Smart TV 32” in sleeping area push-up
- 4G router installed
- HD Mechatronic satellite dish installed
- Control Centre
- LED lighting
- Fully waterproof equipped bathroom: large size type
- Sliding window with matt glass
- Shower with glass door
- Tecma hydro-electric toilette
- Corian integrated basin
- Mirror
- Vanity unit
- Drawers and closet next to toilet
- High closet with shelves
- High closet with doors in the gangway with cloth hanger
- LED lighting
- Humidity aspirator
Featuring space for 5 horses, arranged diagonally in a fishbone pattern
- Fully upholstered stainless-steel partitions, including 2 split-partitions
- Floor covered with waterproof plywood and non-slip-rubber
- The lower half of the walls coated with rubber
- LED lights white and blue for night driving
- Stainless steel blanket rack
- Horizontally sliding windows behind horses
- Vertically sliding windows in front of the horses with stainless steel turn- able protective grill
- CCTV for monitoring horses and aiding in reversing
- Temperature sensor with a display in the driver's cabin
- Turbo fans, remotely controllable from the driver’s cabin
- Special roof hatches
- Power socket for winch and plug in for remote control cable
- Entrance door at the rear right, with window and stainless-steel protection grill
- Folding stair
- Code lock system
